Description
Building upon the legacy of its predecessors, the faster-than-ever Roadmachine 01 combines speed, comfort, and versatility, redefining the ultimate endurance rocket. Crafted from our premium 01-grade carbon, it takes integration to the next level with sleek cable routing, down tube storage, and a seamlessly integrated rear light for maximum safety on long rides. Engineered to accommodate larger tires and designed for maximum compliance, it smooths out rough roads while conserving your energy. Comfort has never been this fast. Equipped with a full SRAM Red groupset, including a power meter, the exceptional DT Swiss ERC wheelset, and our own ICS Carbon Evo one-piece cockpit for unrivaled control, the Roadmachine 01 stands as the flagship of the range – the pinnacle of endurance bikes.
Frameset
Frame:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
Fork:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology stealth cable routing | Flat Mount Disc | 12 x 100mm Thru-Axle | 50mm offset (Size 47-51) 45mm offset (Size 54-61)
Cockpit
Handlebar:
ICS Carbon Evo | One Piece Full Carbon Cockpit | 127mm drop, 70mm reach, 8° flare
Seat
Seatpost:
Roadmachine 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle:
Selle Italia Novus Boost Evo Superflow | CarboKeramic Rail | 145mm
Drivetrain
Crankset:
SRAM Red AXS (FC-RED-P-E1)
Chainrings:
46-33T
Power Meter:
SRAM Red AXS Power Meter (FC-RED-P-E1)
Cassette:
SRAM Red (CS-XG-1290-E1)
Cassette Size:
10-36T
Chain:
SRAM RED (CN-RED-E1)
Front Derailleur:
SRAM RED AXS (FD-RED-E-E1)
Rear Derailleur:
SRAM Red AXS (RD-RED-E-E1)
Shifters:
SRAM Red AXS (ED-RED-E1)
Gears:
2 x 12
Bottom Bracket:
SRAM Press Fit DUB
Brakes
Brake Levers / Calipers:
SRAM Red AXS (ED-RED-E1)
Rotors:
SRAM Paceline X | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
DT Swiss ERC 1100 DICUT | 45mm
Hubs (F/R):
DT Swiss 180 DICUT | Ratchet EXP 36
Tires:
Vittoria Corsa N.EXT | Tubeless | 32mm
Tubeless Information:
Tubeless Rim | Tubeless Tires
Accessories
In the Box:
Integrated Rear Light 25 | Roadmachine Bottle Cages | Storage Pouch | Computer mount for Garmin and Wahoo
Additional Information
Tire Clearance:
up to "40mm measured" (frameset clearance) but limited to "36mm measured" by the front derailleur
Weight without Pedals:
7.5kg | Size 54 as pictured with all accessories
