Description
Marlin 7 is your best friend on the trail and wherever else you roll thanks to its confidence-boosting trail geometry. It finds the perfect balance between price and performance with a RockShox suspension fork that makes quick work of rocks and bumps in your path, and tons of gears from the SRAM NX Eagle 12-speed drivetrain.
Wheel size:
X-Small – Small: 27.5-inch
Medium – XX-Large: 29-inch
Specs
| Frame | X-Small: Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew. Small - X-Large: Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew |
|---|---|
| Fork | X-Small - Small: RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel. Medium - XX-Large: RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
| Rims | X-Small - XX-Large: Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve |
| Hubs | Front: Formula DC-20 LW, alloy, 6-bolt, 100x5mm Rear: Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5mm |
| Tires | X-Small - Small: Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60tpi, 27.5x2.40. Medium - XX-Large: Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40 |
| Bottom Bracket | Truativ Powerspline, 73mm, threaded cartridge, 118mm spindle |
| Crankset | X-Small - Medium: SRAM SX Eagle, 30T steel ring, 49mm chainline, 170mm length. Medium/Large - XX-Large: SRAM SX Eagle, 30T steel ring, 49mm chainline, 175mm length |
| Shifters | SRAM SX Eagle, 12 speed |
| Rear Derailleur | SRAM NX Eagle, 12 speed |
| Cassette/Freewheel | SRAM PG-1210 Eagle, 11-50, 12 speed |
| Chain | SRAM SX Eagle, 12 speed |
| Brakes | Shimano MT200 hydraulic disc |
| Rotors | Shimano RT26, 6-bolt, 160mm |
| Handlebars | X-Small: VP-536 nylon platform. Small: Bontrager alloy, 31.8mm, 15mm rise, 720mm width. Medium - XX-Large: Bontrager alloy, 31.8mm, 15mm rise, 750mm width. |
| Tape/Grips | Trek Line Comp, nylon lock-on |
| Stem | X-Small - Small: Bontrager Comp, 31.8mm, 7 degree, 35mm length. Medium - Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length. X-Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length. XX-Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length |
| Headset | Semi-integrated, 1-1/8'' |
| Seatpost | X-Small - Small: TranzX JD-YSI34, 100mm travel, internal routing, 31.6mm, 350mm length. Medium: TranzX JD-YSI34, 125mm travel, internal routing, 31.6mm, 405mm length. Medium/Large - Large: TranzX JD-YSI34, 150mm travel, internal routing, 31.6mm, 456mm length. X-Large - XX-Large: TranzX JD-YSI34, 170mm travel, internal routing, 31.6mm, 500mm length. |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Pedals | VP-536 nylon platform |
* Subject to change without notice.
