Description
SPECS
Frameset
- Frame: 400 series OCLV Carbon, internal routing, 3s chain keeper, DuoTrap S compatible, mudguard mounts, flat-mount disc, 135x5 mm ThruSkew
- Fork: Carbon, hidden fender mounts, flat mount disc, 100x5mm thru-skew
Weight
- Weight: M - 10.90 kg / 24.04 lbs
- Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
Drivetrain
- Shifter: Shimano CUES U6000 w/optical gear display, 10 speed
- Rear derailleur: Shimano CUES U6000 GS
- Crank: Prowheel alloy, 42T narrow-wide ring, 175 mm length
- Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed
- Chain: Shimano LG500
- Pedal: Bontrager City pedals
- Max chainring size: 1x: 44T
Wheels
- Hub front: Formula CL-51 alloy, 100x5mm QR
- Skewer front: 135x5mm bolt-on
- Hub rear: Formula CL-52 alloy, 135x5mm QR
- Skewer rear: 169x5mm bolt-on
- Rim: Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve
- Tire: Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40 c
- Max tire size: 42mm without fenders
Components
- Saddle: Bontrager Commuter Comp
- Seatpost: Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- *Handlebar:
- Size: XS, S: Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
- Size: M, L, XL: Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
- Grips: Trek Ergonomic Pro, lock-on
- *Stem:
- Size: XS: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
- Size: S, M: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
- Size: L, XL: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
- Brake: Shimano hydraulic disc, MT201 lever, UR300 caliper
- Brake rotor: Shimano RT10, CenterLock, 160 mm
- Rotor size: Max brake rotor sizes: 160mm front & rear
